The LIVI/X, made in Italy, automation for sliding gates is intended for moving residential gates raging from weight ratings of 400kg (LIVI/4), 600kg (LIVI/6 & LIVI/6 BOOST), and 900kg (LIVI/9). The LIVI/X motor for sliding gates, like REV and GULLIVER, is robust because we use solid materials, resistant to mechanical and time wear, such as the metal gears and the aluminium base. A guarantee of quality that never lets you down. LIVI/X is a precise and safe automation for sliding gates because it is equipped with a movement reading system which uses a magnetic or digital encoder. The card controls the movement of the gate, detects the presence of obstacles and when it finds them, reverses the direction of travel. In addition to external safety accessories, such as photocells and safety edges, the encoder makes the gate even more reliable. The card controls the movement of the gate, detects the presence of obstacles and, when it find them, reveres the direction of travel. In addition to external safety edges, the encoder makes the gate even more reliable. All models of LIVI/X – FAST24 are equipped with magnetically operated limit switches. The stroke is very easy to calibrate by simply placing the magnets on the rack at the desired opening and closing endpoints. Thanks to the App DEA user, you can use your smartphone to open your gate without the need for keys or remotes. Moreover, if you have also installed NET-COM with data SIM, you can check the automation status even when you are in the office or away from home.

Kit Contains:

• Motor
• x2 Ziggy – 2 Channel Remotes
• Controller
• Receiver
• 4m Gear Rack (1m long, 6 Fixing Points. Nylon with Steel Core)

Features:

• Speed Adjustment and Slowdown in Opening and Closing
• Magnetic Limit Switches
• Control board positioned in a lifted position at the front. Accessible and perfect for small spaces
• Up to 900kg
• 24V
• Residential use
• Operators with encoder
• Available in fast version, BOOST models (16m/min)

EXCELLENT MATERIALS

The LIVI/X motor for sliding gates, like REV and GULLIVER, is robust because we use solid materials, resistant to mechanical and time wear, such as the metal gears and the aluminium base. A guarantee of quality that never lets you down.

SAFE AND RELIABLE IN ANY SITUATION

LIVI/X is a precise and safe automation for sliding gates because it is equipped with a movement reading system which uses a magnetic or digital encoder. The card controls the movement of the gate, detects the presence of obstacles and, when it finds them, reverses the direction of travel. In addition to external safety accessories, such as photocells and safety edges, the encoder makes the gate even more reliable.

IS THE POWER OUT? YOUR GATE WON’T STOP

What if a sudden blackout blocks your gate? In the 24V version, LIVI/X is battery powered. In case of power failure, the gate will continue to operate as if nothing had happened. Moreover, to enter and exit it is possible to unlock the automation mechanism and open the passage manually, this can be done either from the inside with the special key provided or even from the outside thanks to BLINDOS. With LIVI/X you will never be locked in or out of the house.
