Description

Hydraulic SureClose® Gate Closers & Hinges are designed to replace conventional, bulky commercial gate hinges and closers. These strong and sturdy hinge-closers provide smooth, bind-free performance. Superb engineering and patented design allow clever concealment of the hydraulics in a remarkably small housing. There is no compromise of quality with these small-footprint SureClose® gate closers and hinges. Each ‘ReadyFit’ model lives up to its name by providing convenient screw slots and holes for sturdy fixing. 25mmx12g self-drilling Tek screws are supplied. The slots allow fine vertical adjustment for speedy gate alignment. Horizontal adjustment is attained by way of a built-in, adjustable locking ring that rotates in or out as required to ensure the gate is level and overall alignment is achieved. It’s remarkably simple for a commercial-style gate closer product. All SureClose® Hinges and Closers are made of high-grade aluminium. Optional, L-shaped steel mounting brackets can either be welded or fastened to appropriate gate frames and posts. Weld-on model (NB Steel Bracket) is available by special order.

Features:

• Commercial-Grade, Plain Hinge
• Contains no Hydraulics and is NOT Self-Closing
• Can be Used Alone or in Conjunction with Readyfit Hydraulic Closer
• Easily Retro-Fitted to Existing Gates.
• Alignment Legs Give Double Face-Fixing Strength
• For Gate Gaps of 12-35mm

Technical Specifications:

• Product Code – DD-ALI RF 74001313 SMS plain
• Gate Application – Front Gate, Side Gate, Pedestrian Gate, Pet Gate, Playground Gate, Public/Commercial Gate, Security Gate, Privacy Gate
• Hinge Type – Manual Closing
• Gate Material – Aluminium, Steel/Ornamental Iron
• Self-Closing Gate Weight – Up to 120kg (260lbs)
• Maximum Gate Size – 1.0m W x 1.8m H (4ft x 6ft)
• Gate Frame/Post Shape – Square-to-Square
• Minimum Post Size – 50mm+ (2″)
• Ideal Gate Gap – 12-35mm (½-1½”)
• Fixing Method – Screw-On or Weld-On
• Colour – Black Anodised

NZ Building Product Information – Click Here
